GE IC697MDL750 Discrete Output Module

Description

The GE IC697MDL750 is a discrete output module from the Series 90-70 family, originally developed by GE Fanuc and now supported by Emerson Automation. It provides high-density DC output capability, making it ideal for industrial control systems requiring reliable switching of multiple loads.

Specifications

• Series: GE Fanuc Series 90-70
• Output Channels: 32 discrete outputs, grouped into 4 sets of 8
• Output Voltage Range: 20–60 VDC
• Rated Voltage: 24/48 VDC
• Output Current: 0.5 A per point, 2 A per group
• Inrush Current: 10 A for 20 ms
• Voltage Drop: Max 1 V per output
• Leakage Current: Max 1 mA
• Response Time: 1 ms (on/off)
• Isolation: 1500 V (field to logic), 500 V (group to group)
• Current Draw: 0.25 A from 5V bus
• Mounting: Single-slot module for Series 90-70 baseplate

Features

• High-Density Output: Controls up to 32 devices in a compact form
• Group Isolation: Enhances fault tolerance and system reliability
• Removable Terminal Block: Simplifies wiring and maintenance
• Positive Logic Output: Suitable for sourcing configurations
• VME Standard Compliance: Ensures compatibility with industrial systems
• Durable Design: Built for harsh environments with robust electrical protection
