GE IS200EDCFG1AED Exciter DC Feedback Board

Description

 The GE IS200EDCFG1AED is an Exciter DC Feedback Board designed for the EX2100 Excitation Control System. It plays a critical role in measuring field voltage and current from the SCR bridge, ensuring precise and reliable excitation control in turbine systems.

Specifications

• Part Number: IS200EDCFG1AED
• Manufacturer: General Electric (GE)
• Series: Mark VI / EX2100
• Product Type: Exciter DC Feedback Board
• Dimensions: Approx. 35 cm × 17 cm × 10 cm
• Weight: 0.36 kg
• Mounting Method: Panel-mounted inside EX2100 cabinet
• Communication Interface: Fiber-optic link to EISB board
• Fiber Types Supported: Plastic (up to 10 meters), Hard-Clad Silica (up to 90 meters)
• Power Supply Requirement: ±15V DC (externally supplied)
• Status Indicator: One green LED labeled “PSOK”

Features

• Voltage Isolation: Achieved via fiber-optic communication, protecting sensitive components from electrical interference
• Noise Immunity: High resistance to EMI, ensuring accurate data transmission in industrial environments
• Real-Time Measurement: Captures field current and voltage directly from the SCR bridge for precise control
• Surface-Mount Technology: Enhances reliability and compactness of the board
• System Compatibility: Seamlessly integrates with GE’s EX2100 Excitation Control System
• LED Status Monitoring: Provides visual confirmation of power supply status for quick diagnostics
