GE IS200JPDEG1AAA DC Battery Power Distribution Board

Description

The GE IS200JPDEG1AAA is a DC Battery Power Distribution Board from the Mark VIe series, engineered to deliver stable and isolated DC power to turbine control systems. It’s optimized for high-reliability industrial environments, especially in gas and steam turbine applications.

Specifications

• Model Number: IS200JPDEG1AAA
• Series: Mark VIe
• Type: DC Battery Power Distribution Board
• Input Voltage Range: 18–32 VDC
• Nominal Input Voltage: 24–28 VDC
• Input Isolation: 1500 V AC
• Voltage Rejection: 60 V RMS
• Number of Channels: 24
• Mounting: DIN-rail mounting
• Technology: Surface mount
• Operating Temperature: -40°C to +70°C
• Dimensions: Approx. 16.5 x 17.1 x 5 cm
• Weight: 0.3–0.4 kg

Features

• High Voltage Isolation: Ensures safe and stable power delivery across channels
• Multi-Channel Output: Supports up to 24 output channels for broad distribution
• Fuse Protection: Each output is individually protected for enhanced safety
• DIN-Rail Mounting: Simplifies installation in compact control cabinets
• Industrial Durability: Designed for harsh environments and critical applications
• System Compatibility: Seamlessly integrates with GE Mark VIe turbine control systems
• Redundant Power Support: Capable of supporting multiple power buses for reliability
