HIMA F35011 Safety I/O Module

Description

The HIMA F35011 is a safety I/O module designed for fail-safe signal processing in industrial automation applications. It is part of the HIMatrix safety system, ensuring high-reliability operation in critical control environments. This module is SIL 3 certified, making it suitable for safety-critical applications in sectors such as oil and gas, power generation, and manufacturing.

Specifications

• Safety Integrity Level: SIL 3 (IEC 61508)
• Input Channels: 8 digital inputs (24 V DC)
• Input Voltage Range: 19.2-30 V DC
• Input Current: 6 mA (typical)
• Response Time: <15 ms
• Output Channels: 4 relay outputs
• Relay Contact Rating: 2 A @ 250 V AC / 30 V DC
• Operating Temperature: -40°C to +70°C
• Power Supply: 24 V DC (18-32 V DC range)
• Power Consumption: 3 W (typical)
• MTBF: >100 years (calculated)
• Dimensions: 45 × 120 × 117 mm (W × H × D)
• Weight: 350 g

Features

• Redundant signal processing for enhanced reliability
• Hot-swappable design for minimal downtime
• Integrated diagnostics for real-time monitoring
• Compact form factor for space-efficient installation
• Designed for harsh industrial environments
