HIMA F60PS01 F60 PS 01 Power Supply Module

Description

The HIMA F60 PS 01 is a safety-rated power supply module designed for the HIMatrix F60 system. It delivers all required operating voltages to the system’s programmable electronic components, with galvanic isolation to ensure safe and reliable operation in critical environments.

Specifications

• Model Number: F60 PS 01
• System Compatibility: HIMatrix F60 modular platform
• Supply Voltage: 24 VDC (SELV/PELV compliant), -15% to +20%, ripple ≤ 15%
• Output Voltages: 3.3 VDC / 10 A, 5.0 VDC / 2 A, 24 VDC / 32 A
• Current Input (Max.): 30 A
• External Fusing: 32 A
• Protection Class: III (IEC/EN 61131-2)
• Pollution Degree: II
• Altitude Limit: < 2000 m
• Operating Temperature: 0°C to +60°C
• Storage Temperature: -40°C to +85°C
• Humidity Range: 10–90% RH, non-condensing
• Mounting Location: First left slot of HIMatrix F60 rack
• Dimensions: Approx. 196 × 60 × 140 mm
• Weight: ~1.5 kg

Features

• Galvanic Isolation: Ensures safe separation between voltage levels
• Safety Monitoring: Automatically shuts down if output voltages exceed limits
• Diagnostic LEDs: Front panel indicators for voltage status and fault detection
• Compact Design: Space-saving module with fanless cooling
• Robust Construction: Operates reliably in harsh industrial conditions
• Modular Integration: Seamlessly fits into HIMatrix F60 architecture
• Maintenance-Friendly: Pluggable connectors and clear fault contact interface
• Certified Safety: TÜV-approved for high-integrity safety applications
