HIMA HIMatrix F3DIO16/801 F3 DIO 16/8 01 Safety-Related Controller
HIMA HIMatrix F3DIO16/801 F3 DIO 16/8 01 Safety-Related Controller
HIMA HIMatrix F3DIO16/801 F3 DIO 16/8 01 Safety-Related Controller

    HIMA HIMatrix F3DIO16/801 F3 DIO 16/8 01 Safety-Related Controller

      Description

      Product Description:

      The safety-related F3 DIO 16/8 01 remote I/O is a compact system in a metal housing with 16 digital inputs, 8 2-pole digital outputs, and 2 pulsed outputs. The 2-pole outputs consist of 2 switches connected in series, one switching to L+ and the other switching to L-. The remote I/O is available in various model variants for SILworX and ELOP II Factory, see Table 4. Remote I/Os are connected to individual HIMax or HIMatrix controllers via safeethernet. They are used to extend the I/O level but are not able to run any user program by themselves. The remote I/O is suitable for mounting in Ex-zone 2, see Chapter 4.1.6. The device is TÜV-certified for safety-related applications up to SIL 3 (IEC 61508, IEC 61511, and IEC 62061), Cat. 4, and PL e (EN ISO 13849-1), and SIL 4 (EN 50126, EN 50128, and EN 50129). Further safety standards, application standards, and test standards are specified in the certificates available on the HIMA website.

      Safety Function:

      The remote I/O is equipped with safety-related digital inputs and outputs. The input values on the inputs are safely transmitted to the connected controller via safeethernet. The outputs are safely assigned their values by the connected controller via safeethernet.

      Designation Description:

      • F3 DIO 16/8 01 Remote I/O (16 digital inputs, 8 2-pole digital outputs, 2 pulsed outputs) Operating temperature: 0...+60 °C, for ELOP II Factory programming tool
      • F3 DIO 16/8 01 SILworX Remote I/O (16 digital inputs, 8 2-pole digital outputs, 2 pulsed outputs) Operating temperature: 0...+60 °C, for SILworX programming tool
      • F3 DIO 16/8 014 SILworX Remote I/O (16 digital inputs, 8 2-pole digital outputs, 2 pulsed outputs) Operating temperature: -25...+70 °C (temperature class T1), Vibration and shock tested according to EN 50125-3 and EN 50155, class 1B according to IEC 61373, for SILworX programming tool
