HIMA Z 6012 Fan Module with Monitoring Capabilities

Description

The HIMA Z6012 is a compact fan module designed for the HIMA H51q safety system. It provides reliable cooling and integrates real-time monitoring of fan operation and fuse status to ensure uninterrupted performance in safety-critical industrial environments.

Specifications

• Model: Z6012
• Type: Fan Module with Monitoring Capabilities
• Supply Voltage: 24 V DC
• Power Consumption: Max. 5 W
• Fuse Rating: 4 A T/slow, 5 × 20 mm
• Alarm Output: Relay contact, 24 V DC, 1 A
• Monitoring Functions:
  • Fan run monitoring
  • Fuse failure detection
• Mounting: Integrated into K1412A/B central rack
• Operating Temperature: –25°C to +60°C
• Storage Temperature: –40°C to +85°C
• Humidity Range: 10–90% RH, non-condensing
• Dimensions: 100 mm × 50 mm × 80 mm
• Weight: Approx. 0.2 kg
• Origin: Germany
• Warranty: 1 year


Features

• Integrated Monitoring: Continuously checks fan operation and fuse integrity
• Compact Design: Space-efficient for rack-mounted safety systems
• Real-Time Fault Signaling: Relay output alerts control systems to failures
• System Compatibility: Tailored for HIMA H51q safety platforms
• Industrial Reliability: Built for harsh environments and extended operation
• Preventive Maintenance Support: Enables early fault detection to reduce downtime
