Honeywell 05701-A-0302 Single Channel Control Card

Description

This 05701-A-0302 control card is part of Honeywell's Zellweger Analytics System 57, which is tailored for gas detection and monitoring. The 05701-A-0302 module provides precise control, display, and alarm functionalities for connected gas detectors, ensuring reliable performance in industrial environments.

Specifications

• Power Consumption:

  • Catalytic: 3.75W (typical), including the catalytic sensor.

  • 4-20mA: 3.25W (typical).

• DC Supply Voltage: 18V to 32V DC.

• Dimensions:

  • Length: 17 cm.

  • Width: 2.5 cm.

  • Height: 11.2 cm.

• Weight: 0.165 kg (0.36 lbs).

• Display: Four-part liquid display system:

  • Analog Display: 25-segment for clear indication.

  • Digital Display: Four-character numerical readout.

  • Message Display: Four-character system messages.

  • Icon Section: Power On and Card Select indicators.

Features

• Advanced Gas Alarm Monitoring: Supports multiple alarm levels (A1, A2, A3) for gas detection.

• Push-Button Controls: Includes Alarm Reset and Card Select functions for user convenience.

• Low Electronic Drift: Less than ±2% over six months for stable performance.

• Hot-Swappable: Allows easy replacement without system downtime.

• Integration Capability: Seamlessly integrates with other automation systems using standard communication protocols.
