Honeywell 05701-A-0361 Engineering Card

Description

This 05701-A-0361 module provides a common interface for configuring and operating each fitted control card. It features tactile push-buttons and LED indicators on the front panel, enabling real-time checks of alarm levels, signal spans, and other performance metrics.

Specifications

• Part Number: 05701-A-0361
• Product Type: Engineering Card
• Power Supply: 18–32 VDC
• Power Consumption: 1.5 W (typical)
• Dimensions: 132 mm (H) × 25 mm (W) × 170 mm (D)
• Weight: 152 g
• LED Indicators:
  • Power On: Green
  • Unlocked: Red
• Push-Button Functions:
  • Up / Down
  • Reject / Accept
  • Print (Up + Down together)
• Operating Frequency: 1000 Hz
• Temperature Rating: Up to 100°C
• Interface Ports: 4
• Corrosion Resistance: Yes

Key Features

• Bead mA alarms, zero signal, span, inhibit, and clock functions
• Plug-and-play configuration for simplified setup
• High-speed update rates for torque, speed, and position loops
• Robust design for power plant and high-demand industrial environments
• Supports full maintenance and setup for each channel card
