Honeywell 05701-A-0511 Rack Assembly

Description

The Honeywell 05701-A-0511 is a full-size 19-inch, 3U-high rack assembly designed for rear field wiring connections. It serves as a modular housing unit for the System 57 control system, supporting gas detection and automation operations in industrial environments.

Specifications

• Rack Type: Full 19" wide x 3U high
• Channel Capacity: Supports up to 16 control channels
• Dimensions: 38 x 17.4 x 13 cm
• Weight: 1.5 kg
• Field Wiring: Rear connection format
• Power Interface: DC Input Card or direct-to-control card for high-integrity setups
• Warranty: 12 months (varies by supplier)
• Product Origin: USA

Features

• Modular Architecture: Houses Channel Control Cards, Engineering Card, and DC Input Card
• Dual-Chamber Design: Separates control cards from field/relay interface cards for EMI shielding
• Backplane Communication: Enables signal routing and power distribution across modules
• Flexible Alarm Handling: Each control card manages basic alarms; complex logic handled via backplane
• Maintenance-Friendly: Engineering Card supports diagnostics and system interrogation
• Expandable System: Optional modules allow enhanced output and integration
• Robust Construction: Built for demanding industrial applications with high reliability
