Honeywell 05701-A-0550 System 57 Calibration Plug

    Honeywell 05701-A-0550 System 57 Calibration Plug

      Description

      Features:

      • Backlit LCD display
      • Bar graph and peak value reading
      • LED indicator lights
      • Buttons
      • Remote reset and inhibit functions
      • 18V to 32V DC power supply

      Specifications:

      • Display/Alarm points: Linearity 2%, repeatability 2%
      • Electronic drift: Less than 3%/6 months
      • Operating temperature: -5°C to +55°C
      • Storage temperature: -25°C to +55°C
      • Operating humidity: 20-90% RH (non-condensing)
      • Dimensions: 3U high x 25mm wide
      • Weight: 165g
      • Approval: EN50270

      Catalytic Bridge Input:

      • Drive mode: Constant current
      • Current range: 90mA to 315mA
      • Full scale range: 15mV to 300mV
      • Maximum line resistance: 40 ohms (including sensor)

      4-20mA Input:

      • Loop power supply voltage: 24V ± 5% isolated
      • Sensor configuration: Current source
      • Signal measurement range: 0 to 25mA
      • Maximum loop resistance: 500 ohms (including sensor)

      Analog Output Options:

      • Measurement signal range: 0 to 20mA or 4-20mA
      • Input linearity: Better than 2% FSD
      • Input repeatability: Better than 1% FSD
      • Configuration: Isolated current sink or source (with external power supply)

      NEW AND ORIGINAL ITEM IN STOCK

      WITH ONE YEAR WARRANTY

      Hope anyone inquire from us, please click this sales7@cambia.cn

      1. Lower your support costs
      2. Provide ongoing availability of automation replacement parts
      3. Quantity available: 10
      4. Warranty: 12 months

      Technical specification, manuals, and data sheets.

      Inquiry details, please pay attention as below:

      1. All quotes based on EXW only
      2. Shipping time: 5-7 days, via DHL/TNT/UPS/EMS/Fedex..
      3. Payment terms: 100% T/T PAYMENTS before shipping
