Honeywell 51304640-125 Digital Input Field Termination Assembly

Description

The Honeywell 51304640-125 is a Digital Input Field Termination Assembly (FTA) designed to interface digital input signals with Honeywell control systems. It provides galvanic isolation for enhanced safety and signal integrity, making it ideal for demanding industrial environments.

Specifications

• Model Number: 51304640-125
• Product Type: Digital Input FTA
• Input Channels: 32 digital inputs
• Voltage Range: 24 VDC
• Galvanic Isolation: Yes (recommended module: MTL4016 – 51191699-100)
• Terminals: Compression-type connections
• Max Open Circuit Voltage: 10.5 V
• Max Short Circuit Current: 14 mA
• Min Source Resistance: 800 ohms
• Max Applied Voltage: 250 V RMS
• Operating Temp: -40°C to +70°C
• Dimensions: 10.8 cm × 6.7 cm × 8.4 cm
• Weight: Approx. 0.5 kg

Key Features

• High-Density Input: 32-channel digital input capacity
• Electrical Isolation: Galvanic isolation enhances safety and reliability
• Compact Design: Space-efficient for control cabinets
• Robust Build: Operates reliably in harsh industrial conditions
• Redundancy Support: Ensures system availability and fault tolerance
• Ease of Wiring: Compression terminals simplify installation and maintenance
