Honeywell 8C-SHEDA1 51307186-175 Header Board

Description

The Honeywell 8C-SHEDA1 is a header board used in the Experion Process Knowledge System (PKS). It serves as a critical interface for connecting I/O modules to the PKS controller, enabling efficient power distribution and RS-485/IOLINK communication. Engineered for durability and seamless integration, it supports up to 8 I/O modules and is ideal for demanding industrial environments.

Specifications

• Model: 8-SHEDA1
• Part Number: 51307186-175
• Type: Header Board
• Primary Function: Distributes 24 VDC power and supports IOLINK communication
• Input Voltage: 110 VAC or 220 VAC
• Output Voltage: 24 VDC
• Communication Interface: RS-485 (up to 115.2 kbit/s)
• I/O Capacity: Supports up to 8 I/O modules
• Connectors:
  • 3 combo cable connectors (4 pairs of 6 pins)
  • 2 IOLINK extensions (2 pairs of 3 pins)
• Mounting Type: Panel mount
• Dimensions: 172 mm × 102 mm × 41 mm
• Weight: 0.34 kg
• Operating Temperature: 0°C to +60°C
• Storage Temperature: −40°C to +85°C
• Humidity: 5% to 95% RH, non-condensing
• Certifications: CE, TUV, UL508, CSA
• Warranty: 12 months
• Country of Origin: USA


Features

• Efficient Power Distribution: Supplies 24 VDC to connected I/O modules
• Reliable Communication: RS-485 and IOLINK support for fast, stable data exchange
• High Integration Capacity: Connects up to 8 modules for scalable control
• Industrial Durability: Built to withstand harsh conditions and continuous operation
• Compact Design: Streamlined form factor for easy panel mounting
• Environmental Resilience: Operates across wide temperature and humidity ranges
• Certified Quality: Meets global standards for safety and performance
• Optimized System Setup: Simplifies configuration and reduces downtime
