Honeywell 900A16-0101 Analog Input Hi Level Module

Description

The Honeywell 900A16-0101 is an advanced analog input module designed for high-level signal processing in industrial automation systems. It features 16 isolated inputs that support both voltage and current signal types, providing precise and reliable data acquisition.

Key Features and Specifications

• Inputs per Module: 16 (isolated)
• Input Types: Voltage (V) and Current (mA)
• Input Impedance:
  • Voltage Inputs: >1 megohm
  • Current Inputs: 250 ohms
• Galvanic Input Isolation:
  • Point to Point: 400 VDC
  • Solid State Switching
  • To Logic: 1 kVDC
• Noise Rejection:
  • Series Mode: >31 dB
  • Common Mode: >90 dB at 120 VAC
• Over-Range Limit: ±10% for linear voltage ranges
• Temperature Effect on Accuracy: ±0.01% of full scale per degree Celsius maximum
• A/D Converter: One per module
• A/D Resolution: ±15 Bits
• Update Rate: 100 ms (Analog to Digital Converter per module)
• Long Term Stability: 0.1% per year
• Shipping Weight: 2 kg
