Honeywell 900G32-0101 Digital Input Module 24VDC (32 channel)
SKU: 900G32-0101
In stock
Description

Specifications:

  • Manufacturer: Honeywell
  • Product Number: 900G32-0101
  • Product Type: Digital Input 24VDC, 32 Channel
  • Inputs per Module: 32 (sinking)
  • Input Voltage Range: 10 VDC to 32 VDC
  • Peak Voltage: 32 VDC
  • Galvanic Isolation: 2 groups of 16 inputs (30VDC max.)
  • ON Voltage Level: 9.5 VDC minimum
  • OFF Voltage Level: 3.5 VDC maximum
  • Input Impedance: 6.9 K ohms nominal
  • Input Current: 1.7 mA @ 12 VDC, 3.5 mA @ 24 VDC nominal
  • Minimum ON Current: 1.0 mA
  • Maximum OFF Current: 0.7 mA
  • OFF to ON Response Time: 5 ms max
  • ON to OFF Response Time: 5 ms max
  • Power Supply Loading: 5V; 215mA max, 24V; 0mA
  • Dimensions: 137mm H x 35.6mm W
  • Weight: 0.175 kg
