Honeywell CC-PDIS01 Digital Input Module

Description

The Honeywell CC-PDIS01 is a Digital Input Sequence of Events (SOE) Module, designed for industrial automation systems. It captures discrete input signals and timestamps events with 1ms resolution, making it ideal for monitoring critical system changes.

Specifications

• Input Channels: 32
• Operating Voltage: 24V DC
• Scanning Modes: Normal (20ms), Low Latency (5ms), SOE (1ms resolution)
• Isolation: 1500 VAC RMS or ±1500 VDC (Galvanic Isolation)
• Input Impedance: 4.2 kΩ
• Dimensions: Standard I/O module size
• Weight: 2 kg

Features

• Supports sequence-of-events recording for precise event tracking
• High-speed scanning for real-time monitoring
• Optional redundancy for enhanced reliability
• Internal or external field power selection
• On-board excitation power, eliminating the need for marshalling power
