Honeywell CC-PUIO31 51454220-176 Universal I/O Module

Function

The Universal Input Output module interfaces with analog input, analog output, digital input, and digital output field devices.

Notable Features

• Each channel user configurable as:
  • Analog Input
  • Analog Output
  • Digital Input
  • DISOE - Sequence of Events (1ms resolution SOE, 20ms PV scan)
  • Digital Output
  • Pulse Input (any four channels)
• Open Wire Detection
• Electronic short circuit protection
• Fast Scan (Priority I/O Module Scan)
• Safe-state (FAILOPT) behaviors configurable on a per channel basis for Digital/Analog Output
• HART 7 support (Analog I/O)
• HART Modem per Channel for Fast Performance
• Extended Temperature Range: -40 to +70°C module ambient

Specifications

• Input Type: Current (2, 3, or 4 wire devices)
• Input Channels: 32 Maximum per module (with or without open wire detect)
• A/D Converter Resolution: 16 bit
• Input Range: 0-20 mA or 4-20 mA
• Normal Mode Rejection Ratio: 18 dB at 50 Hz, 20 dB at 60 Hz
• Input Filter Response: Single pole, -3dB @ 6 Hz
• Crosstalk, dc to 60 Hz (channel-to-channel): 60 dB
• Input Impedance: 250 Ω
• Input Voltage Range: +33 VDC to -1 VDC (any input referenced to common, no damage)
• Input Scan Rate: 10 ms
• Hardware Accuracy:
  • 0.1% of full-scale (23.5 ± 2°C)
  • 0.175% of full-scale (0 to +70°C)
  • 0.25% of full-scale (-40 to +70°C)
• Short Circuit Current Limit: 25 mA

New and Original Item in Stock

• Warranty: One year warranty
• Quantity Available: 10
• Contact: sales7@cambia.cn

Benefits:

• Lower your support costs
• Provide ongoing availability of automation replacement parts

Shipping and Payment Terms:

• All quotes based on EXW only.
• Shipping time: 5-7 days via DHL/TNT/UPS/EMS/FedEx.
• Payment terms: 100% T/T payments before shipping.
