Honeywell CC-TDOR01 Digital Output Relay Module

Description

The Honeywell CC-TDOR01 is a robust Digital Output Relay Module specifically designed for the Experion PKS Series C control system. This module functions as a reliable interface for switching high-current or high-voltage field loads that exceed the capacity of standard electronic outputs. It is built to provide galvanic isolation between the control logic and field devices, ensuring maximum protection and stability for industrial process automation.

Specifications

• Product Number: CC-TDOR01
• Product Type: Digital Output Relay Module
• Output Type: Electromechanical Relay
• System Series: Honeywell Experion PKS Series C
• Net Weight: 0.45 kg
• Shipping Weight: 1.8 kg
• Mounting: Installs onto Series C I/O Termination Assemblies (IOTA)
• Configuration: Supports both redundant and non-redundant installations

Features

• High Switching Capacity: Capable of driving heavy-duty field devices such as motor starters, solenoids, and interposing relays.
• Galvanic Isolation: Provides a physical break between the control system and the field circuit to prevent electrical noise and surge damage.
• On-Board Diagnostics: Features status indicators and self-checking mechanisms to monitor the health of the output channels.
• Redundancy Support: Compatible with redundant IOTA configurations to prevent system trips and ensure continuous process availability.
• Rugged Design: Engineered to withstand the thermal and electrical stresses typical of harsh industrial environments.
