Honeywell FC-BKM-0001 Battery and Key Switch Module

Description:

• Manufacturer: Honeywell
• Product No.: FC-BKM-0001
• Product Type: Battery and Key Switch Module
• Operating temperature: -5°C—+70°C (+23°F—+158°F)
• Storage temperature: -40°C—+85°C (-40°F—+185°F)
• Relative humidity: 10—95% (non-condensing)
• Approvals: CE, TUV, UL, CSA, FM
• 24 V supply voltage: 24 Vdc -15%—+30%
• 24 V supply current: max. 20 mA (out of each 24 Vdc), typ. 7 mA (shared load on 24 Vdc)
• 5 VR supply voltage: 5 Vdc ± 10%
• 5 VR supply current: max. 10 mA
• Output supply voltage: 14—31 Vdc
• Output resistance: approx. 2 × 1.1 kΩ (parallel)
• Short circuit proof: continuous
• Dimensions: 176 × 35.2 × 212 mm (H × W × D)
• Weight: 0.5 kg
