Honeywell FC-QPP-0002 Quad Processor

Product Description

• Manufacturer: Honeywell
• Product Number: FC-QPP-0002
• Product Type: Quad Processor

Specifications

• Operating Temperature:
  • Outside Module Temperature: -5°C to +70°C (+23°F to +158°F)
  • Inside Module Temperature: -5°C to +70°C (+23°F to +158°F)
• Storage Temperature: -40°C to +85°C (-40°F to +185°F)
• Relative Humidity: 10% to 95% (non-condensing)

Electrical

• 24 V Supply Voltage: 24 VDC ±15% to +30%
• 24 V Supply Current: Maximum 25 mA
• 5 V Supply Voltage: 5 VDC ± 5%
• 5 V Supply Current: Maximum 1.2 A
• Output Supply Voltage: 15 VDC to 31 VDC
• Output Resistance: Approx. 1.1 kΩ
• Short Circuit Proof: Continuous
• Voltage (High): 15 to 32 VDC
• Voltage (Low): < 4 V (reverse polarity protected)
• Input Current: Approx. 8 mA at 24 VDC
• Output Current: 750 mA per output

Physical

• Dimensions: 176 mm (H) x 88.5 mm (W) x 212 mm (D)
• Weight: 1.3 kg
• Shipping Weight: 3 kg
