Honeywell FC-SAO-0220M Analog Output Module

Description

This FC-SAO-0220M module provides two independent analog output channels with a range of 0 (4)–20 mA, suitable for controlling actuators or transmitting process values. It features fail-safe operation, making it ideal for use in safety instrumented systems.

Specifications

• Model: FC-SAO-0220M
• Channels: 2 analog outputs
• Output Range: 0 (4)–20 mA
• Output Impedance: 250 ohms
• Input Voltage: 24 VDC
• Power Consumption: 1.5 W
• Response Time: ≤ 1 ms
• Dimensions: 96 × 72 × 50 mm
• Weight: 0.2 kg

Key Features

• Galvanic isolation between outputs and power supply
• Redundant analog output support for enhanced reliability
• Built-in diagnostics with A/D feedback for output verification
• Compact footprint for space-constrained panels
• Compatible with resistive and capacitive loads (not inductive)
• Secondary means of de-energizing via watchdog and processor logic
