Honeywell MP904A504-7 Pneumatic Actuator

Description

The Honeywell MP904A5047-3 is a pneumatic damper actuator engineered for precise control of dampers in HVAC systems. It operates using air pressure to modulate airflow, making it ideal for both commercial and industrial ventilation applications. Its compact design allows for flexible mounting, and it's compatible with a wide range of control systems.

Specifications

• Type: Pneumatic Damper Actuator
• Operating Pressure Range: 21–70 kPa
• Maximum Operating Pressure: 140 kPa
• Safe Air Pressure Limit: 210 kPa
• Stroke: 90 mm
• Force Output: 550–600 N
• Air Connection: Barb fitting for 6 mm (1/4") polyethylene tubing
• Dimensions: Length 225 mm (8-7/8"), Diameter 159 mm (6-1/4")
• Operating Temperature: -30°C to +70°C
• Weight: Approx. 2 kg

Features

• Precise Control: Ensures accurate damper positioning for efficient airflow regulation.
• Durable Construction: Built to withstand demanding HVAC environments.
• Versatile Compatibility: Works with direct-acting controllers and electric-pneumatic relays.
• Compact Design: Suitable for both internal and external mounting.
• Reliable Performance: Maintains full main air pressure to actuators at all times.
