IC200MDL650 | General Electric | Discrete Input Module

Description

The IC200MDL650 module provides 32 discrete input points, organized into four groups of eight. It supports both positive and negative logic inputs, making it versatile for various industrial applications. This module is part of the VersaMax I/O family, known for its compact design and reliable performance.

Specifications

• Input Voltage: 24 V DC.
• Input Type: Positive/Negative logic.
• Number of Inputs: 32 (4 groups of 8).
• Input Current: 7 mA typical at 24 V DC.
• Response Time: Configurable input filter with response times of 0.5 ms, 1.5 ms, or 7.5 ms.
• Isolation:
  • User input to logic: 250 VAC continuous, 1500 VAC for 1 minute.
  • Group-to-group: 250 VAC continuous, 1500 VAC for 1 minute.
• Backplane Current Consumption: 50 mA maximum at 5 V DC.
• Operating Temperature: 0°C to 60°C (32°F to 140°F).

Features

• Flexible Logic: Supports both positive and negative logic inputs for diverse applications.
• LED Indicators: Each input point has an individual LED to indicate its on/off status.
• Compact Design: Space-saving form factor for easy integration into VersaMax systems.
• Durable Construction: Built to withstand industrial environments.
• Ease of Configuration: Software-configurable input filters for noise suppression and signal stability.
