ICS Triplex T9482 Analog Output Module

Description

The ICS Triplex T9482 is an 8-channel isolated analog output module designed for high-reliability industrial control systems. It delivers precise current signals to field devices and supports fault-tolerant configurations for safety-critical applications.

Specifications

• Model: T9482
• Output Channels: 8 isolated, current sink type
• Output Range: 4–20 mA
• Compliance Voltage: 18–32 VDC
• Max Voltage (No Damage): 60 VDC
• Max Load Impedance: 0–750 Ω
• Update Rate: 10 ms per channel
• Resolution: 15-bit control, 13-bit monitoring
• Accuracy: ±0.5% of full scale (typical)
• Isolation Voltage: 1500 VDC between channels
• Processor: 32-bit RISC
• Memory: 64 MB RAM, 64 MB Flash
• Power Supply: Redundant +24 VDC (18–32 VDC range)
• Power Dissipation: 3.6 W (typical), 20 W (maximum)
• Operating Temperature: -20°C to +60°C
• Dimensions: 4 × 12.3 × 16.5 cm
• Weight: 0.36 kg


Features

• High Precision Output: Delivers stable and accurate 4–20 mA signals for process control
• Fault Tolerance: Dual-module mode enhances reliability by sharing current load
• Modular Design: Easily expandable and customizable for specific applications
• Fast Response: 10 ms update rate per channel for real-time control
• Advanced Diagnostics: Built-in fault detection and monitoring capabilities
• Robust Isolation: 1500 VDC isolation between channels ensures safe operation
• Flexible Communication: Supports Ethernet, Modbus, and Profibus protocols
• Wide Compatibility: Integrates seamlessly with ICS Triplex AADvance systems
• Safety Certified: TÜV-approved for use in SIL 2 and SIL 3 environments
