INVENSYS FOXBORO FBM239 Discrete 16DI/16DO Interface Module

SKU: FBM239
In stock
Description

Key Features:

  • Sixteen digital input channels, used for either contact sensing or DC voltage monitoring.
  • Sixteen digital output channels, used for either DC output switching with an external source (e.g., to control powering of various external loads) or DC output switching with an internal source only (e.g., to power external solid-state relays or similar devices).
  • Compact, rugged design suitable for enclosure in Class G3 (harsh) environments.
  • Supports discrete input signals at voltages of:
    • 30 V DC / 60 V DC
    • 120 V AC / 125 V DC
    • 240 V AC
  • Supports output switching at voltages of:
    • 60 V DC
    • 120 V AC / 125 V DC
    • 240 V AC
  • Executes programs for Digital I/O (ECB5) and Ladder Logic (ECB8).

Various Termination Assemblies (TAs) provide:

  • Per-channel isolation and 100 Series I/O upgrade.
  • High voltage attenuation and optical isolation for inputs.
  • External power connection for device excitation.
  • Output current limiting.

Specifications:

  • Input/Output Channels: 16 group isolated digital input channels and 16 group isolated digital output channels.
  • Filter/Debounce Time: Configurable (No Filtering, 4, 8, 16, or 32 ms).

Voltage Monitor (FBM239 with feed through TA P0924VJ):

  • Input:
    • 30 V DC maximum applied voltage.
  • ON-STATE VOLTAGE:
    • 15 to 30 V DC.
  • OFF-STATE VOLTAGE:
    • 0 to 5 V DC.
  • CURRENT INPUT FOR ON-STATE:
    • 2.3 mA maximum at 30 V DC.
  • SOURCE RESISTANCE LIMITS:
    • ON-STATE:
      • 1 kΩ (maximum) at 15 V DC.
    • OFF-STATE:
      • 100 kΩ (minimum) at 30 V DC.

Contact Sense (FBM239 with feed through TA P0924VM):

  • CONTACT SUPPLY:
    • 24 V DC nominal (supplied by FBM through the TA).
  • CONTACT CURRENT:
    • 1.8 mA DC nominal.
  • SOURCE RESISTANCE LIMITS:
    • ON-STATE:
      • 1 kΩ (maximum) at 15 V DC.
    • OFF-STATE:
      • 100 kΩ (minimum) at 30 V DC.

Output (FBM239 with feed through TAs P0924VJ or P0924VM):

  • APPLIED VOLTAGE (EXTERNAL):
    • 60 V DC maximum.
  • LOAD CURRENT:
    • 0.24 A DC maximum per channel.
    • 2.0 A DC maximum per TA.
  • INDUCTIVE LOADS:
    • Outputs may require a protective diode or MOV connected across the load.
