Pepperl+Fuchs 226188 FI-PFH-TR-AI-370X-GP Termination Board

System Board for Schneider Electric, Tricon series by Triconex

• TAN48 Approval
• HART Termination Board (ETP) for Tricon v10 AI Module
• For 16-channel AI Cards 3700, 3700A, 3703E, and 3721
• 16-channel
• Field Side: Pluggable Screw Terminals, Green
• Control Side: ELCO Socket, 56-pin

Mechanical Specifications

• Degree of Protection: IP20
• Connection:
  • Field Side: Pluggable Screw Terminals, Green
  • Control Side: ELCO Socket, 56-pin
  • HART: 1 x IDC Plug, 26-pin
  • Supply: Screw Terminals, Green
• Core Cross Section: 0.5 ... 2.5 mm² (20 ... 12 AWG)
• Material:
  • Housing: PVC
• Mass: Approx. 415 g
• Dimensions: 126 x 123 x 59 mm (5.0 x 4.9 x 2.3 inches) (W x H x D)
  • Height: 123 mm
  • Width: 126 mm
  • Depth: 59 mm
• Mounting: On 35 mm DIN Mounting Rail acc. to EN 60715:2001

NEW AND ORIGIN ITEM IN STOCK

WITH ONE YEAR WARRANTY

Hope anyone inquires from us, please click this sales7@cambia.cn

• Lower your support costs.
• Provide ongoing availability of automation replacement parts.

Quantity Available: 10

Warranty: 12 months.
