Schneider Electric MNB-1000 BACnet Plant Controller

Description

The Schneider Electric MNB-1000 is a BACnet Plant Controller designed for building automation systems (BAS). It supports BACnet/IP, BACnet Ethernet, and MS/TP communications, allowing seamless integration into various industrial and commercial environments. The controller features Sensor Link (S-Link) support, remote I/O capabilities, and LED status indicators, making it a versatile solution for HVAC and process control applications.

Specifications

• Dimensions: 278 mm × 213 mm × 58 mm
• Power Supply: 20.4 to 30 Vac, 50/60 Hz
• Power Consumption: 50 VA at 24 Vac
• Operating Temperature: -40 to 60°C
• Humidity: 5 to 95% non-condensing
• Communication Protocols: BACnet/IP, BACnet Ethernet, MS/TP
• I/O Points: 12 universal inputs, 4 digital inputs, 8 universal outputs, 8 digital outputs
• Certifications: UL 916, CE, FCC Part 15, CSA

Features

• Supports BACnet/IP, BACnet Ethernet, and MS/TP for flexible communication
• Panel-mount design with removable electronics module for easy installation
• LED status indicators for quick diagnostics
• Remote I/O support for expanded system capabilities
• Programmable sequence of operation using WorkPlace Tech Tool
• BTL-listed as a BACnet Application-Specific Controller (B-ASC)
