Bently Nevada 990-05-70-03-05 990 Vibration Transmitter

Runto Electronic Automation Limited

Product Number

990-05-70-03-05

990-05-70-03-05
Thrust Transmitter

Bently Nevada 990-05-70-03-05 is a vibration sensor primarily used for industrial equipment condition monitoring and fault diagnosis. It has the following functions:

It can measure the vibration signals of equipment, including acceleration, velocity, and displacement.
Equipped with high-precision vibration sensors, it can monitor and analyze the vibration status of equipment in real-time.
It has multiple installation methods and can be installed on various devices, such as pumps, fans, generators, etc.
It has multiple output signal formats and can output analog signals such as 4-20mA, 0-5VDC, 0-10VDC, as well as digital signals.
There are multiple filtering methods that can be selected according to actual needs.
Equipped with automatic fault diagnosis function, it can automatically detect the working status of sensors and provide alarms.

The parameters for Bently Nevada 990-05-70-03-05 are as follows:

Measurement range: 0-50g (acceleration), 0-25mm/s (velocity), 0-2.5mm (displacement)
Frequency response: 10Hz-1kHz (acceleration), 10Hz-1kHz (velocity), 10Hz-500Hz (displacement)
Accuracy: ± 5% (acceleration), ± 5% (velocity), ± 5% (displacement)
Output signals: 4-20mA, 0-5VDC, 0-10VDC and other analog signals, digital signals
Output range: determined according to different output signal formats
Power supply voltage: DC12-42V
Working temperature: -20 ℃~70 ℃
External dimension: M18x1.5 thread, approximately 80mm long
Installation method: plug-in installation

The above are the main parameters for Bently Nevada 990-05-70-03-05, which may vary depending on product version and configuration.
