Woodward 5453-278 MicroNet 12-Slot Chassis

Description

The Woodward 5453-278 is a 12-slot modular chassis designed for MicroNet control systems. It provides a rugged and scalable platform for integrating control, I/O, and communication modules in industrial automation environments.

Specifications

• Manufacturer: Woodward
• Model Number: 5453-278
• Product Type: MicroNet 12-Slot Chassis
• Slot Configuration: 12 module slots for I/O and transceiver modules
• Power Supply Support: Two positions for redundant power modules (each occupies 3 slots)
• Total Chassis Width: 18 slots including power and I/O modules
• Cooling System: Forced-air cooling with integrated fans and temperature switches
• Bus Standard: VME (VERSAmodule Eurocard) for module communication
• Dimensions: Approximately 350 × 250 × 150 mm
• Weight: Around 3.2 kg (7.05 lbs)
• Operating Temperature: –20°C to +60°C
• Country of Origin: United States

Features

• Modular Flexibility: Supports up to 12 modules for scalable control solutions
• Efficient Cooling: Optimized airflow design prevents overheating and ensures system stability
• Redundant Power Capability: Dual power supply slots enhance reliability in critical applications
• DIN Rail Mounting: Simplifies installation in industrial cabinets and control panels
• Blanking Plate Requirement: Unused slots must be covered to maintain airflow and cooling efficiency
• System Compatibility: Integrates seamlessly with Woodward 505 series and other MicroNet modules
• Fault Isolation: Individual slot protection minimizes system-wide failures
• Application Scope: Ideal for power generation, oil & gas, and manufacturing automation
