Yokogawa ADV151-P50 Analog Input Module

Description

The Yokogawa ADV151-P50 is a high-performance digital input module designed for industrial automation systems. It reliably processes 24 V DC ON/OFF signals and supports dual redundancy for mission-critical applications.

Specifications

• Model: ADV151-P50
• Input Channels: 32 digital inputs
• Rated Input Voltage: 24 V DC (sink/source)
• Input ON Voltage: 18 to 26.4 V DC
• Input OFF Voltage: 5.0 V DC or lower
• Input Current: 4.1 mA ±20% per channel
• Maximum Input Voltage: 30.0 V DC
• Withstanding Voltage: 2 kV AC between input and system (1 minute)
• Common Isolation: 500 V AC between commons (every 16 channels)
• Response Time: ≤8 ms for status input
• Power Consumption: Max 500 mA at 5 V DC
• Weight: 0.30 kg

Features

• ON/OFF Signal Detection: Accurately detects and processes digital status changes
• SOE Capture: Records Sequence of Events data for diagnostics and analysis
• Pushbutton Edge Counting: Supports edge detection for control applications
• High-Speed Input: Handles up to 25 Hz ON/OFF cycles
• Dual Redundancy Support: Ensures system reliability in critical operations
• Compact Form Factor: Ideal for dense control cabinet installations
• Industrial Grade Reliability: Built for demanding environments and long-term use
