Yokogawa ADV551-P50 Digital Output Module

Specifications

• Model: ADV551
• Number of Output Channels: 32
• Rated Applied Voltage: 24 V DC
• External Power Supply Rating: 24 V DC, 50 mA
• External Power Supply Voltage Range: 20.4 to 26.4 V DC
• Output ON Voltage Maximum Value: 2 V DC
• Leak Current Maximum Value When Output OFF: 0.1 mA
• Output Format: Current sink
• *Maximum Load Current (1): 100 mA/channel, 26.4 V
• Withstanding Voltage:
  • Between output signal and system: 2 kV AC, for 1 minute
  • Between commons: 500 V AC, for 1 minute, common minus (–) side every 16-channel (*2)
• Functions:
  • Status Output: ON/OFF status output function
  • Pulse Width Output: One-shot pulse width output function
  • Time-proportioning Output
• Output Response Time:
  • 3 ms or less (for status output)
  • 10 ms or less (for mixed status and pulse outputs)
• Pulse Width: 8 ms to 7200 s
• Pulse Width Resolution: 8 ms, but ON/OFF delay of maximum 1 ms is added
• Maximum Current Consumption:
  • 700 mA (5 V DC)
  • 60 mA (external power supply)
• Weight: Approx. 0.20 kg
• External Connection: Pressure clamp terminal, Dedicated cable (AKB331), MIL connector cable
