Yokogawa AFV10D-S41101 Duplexed Field Control Unit

Description

The AFV10D-S41101 is part of Yokogawa's advanced control systems, offering dual-redundant capabilities for enhanced reliability. It is designed for 19-inch rack mounting and supports Vnet/IP and FIO (Fieldbus I/O) communication. This unit is ideal for applications requiring high precision and dynamic response in motor and process control.

Specifications

• Processor: VR5432 (133 MHz)
• Memory: 32 MB
• Power Supply: Supports 24 V DC or 100–240 V AC
• Power Consumption:
  • 200 VA (100–120 V AC)
  • 230 VA (220–240 V AC)
  • 5.5 A (24 V DC)
• Mounting: 19-inch rack with 8 M5 screws
• Compliance: CE, CSA, FM Non-Incendive, KC Marking
• Weight: Approx. 8 kg
• Environmental Durability: Operates in a temperature range of 0°C to 55°C and humidity of 5% to 95% RH.

Features

• Dual-Redundant Vnet/IP Interface: Ensures continuous operation even in case of a failure.
• Battery Backup: Provides up to 72 hours of power failure protection with a minimum recharge time of 48 hours.
• High Reliability: Designed with redundancy in hardware and software for uninterrupted performance.
• Flexibility: Modular design allows for customization based on application needs.
• Ease of Integration: Supports seamless communication with other Yokogawa systems and third-party devices.
• User-Friendly Design: Simplifies installation and maintenance.
