Yokogawa AMM22 Multiplexer Input Module

Description

The AMM22 is ideal for process control systems, industrial automation, and data acquisition systems. Its flexibility and speed make it a versatile choice for applications requiring efficient signal processing.

Specifications

• Conversion Speed: 50 μs per point (high-speed data acquisition)
• Input Channels: 4 or 8 differential signal inputs (configurable)
• Input Signal Ranges:
  • Voltage: 0 to 5V, 1 to 5V, -10 to 10V, 0 to 10V DC
  • Current: 0 to 20mA DC, 4 to 20mA DC
• Multiplexing: Sequential A/D conversion of 4 or 8 input points
• Isolation: Input terminals are isolated from the internal circuit via photocouplers
• Configurable Conversion Cycle: Selectable from 50 μs to 100 ms
• Dimensions: 5.0" x 1.0" x 8.0" (12.7 cm x 2.5 cm x 20.3 cm)
• Weight: 0.2 kg (6.1 oz)

Features

• High-Speed Data Acquisition – Ensures rapid and accurate signal conversion.
• Flexible Channel Configuration – Supports 4 or 8 differential signal inputs.
• Wide Input Signal Range – Compatible with a broad range of voltage and current signals.
• Signal Isolation – Photocouplers provide isolation between input terminals and the internal circuit.
• Advanced Signal Processing – Features scaling and filtering capabilities to improve signal quality and measurement accuracy.
• Compact Design – Small form factor simplifies installation and reduces space requirements in control panels.
• Robust Performance – Built to handle demanding industrial applications.
