Yokogawa FX1006-4-3-L Paperless Recorder

Description

 Yokogawa FX1006-4-3-L is a compact, high-performance paperless recorder from the FX1000 Value Series. Designed for multi-channel process monitoring, it offers real-time visualization, secure data storage, and robust communication interfaces for demanding industrial applications.

Specifications

• Model: FX1006-4-3-L
• Input Channels: 6 analog inputs
• Measurement Types:
  • DC voltage (DCV)
  • DC current
  • Thermocouple (TC)
  • Resistance Temperature Detector (RTD)
• Display: 5.7-inch TFT color LCD
• Display Modes: Trend, bar graph, digital, overview, alarm, historical trend
• Scan Interval: 1 s or 125 ms (fast sampling)
• Measurement Accuracy:
  • ±0.05% of reading (DCV)
  • ±0.15% of reading (TC, RTD)
• Internal Memory: 400 MB
• External Storage: CompactFlash or SD card (up to 32 GB)
• Communication Interfaces: Ethernet, RS-485
• Power Supply: 100–240 VAC
• Power Consumption:
  • 200 VA (100–120 V AC)
  • 230 VA (220–240 V AC)
• Operating Temperature: –20°C to +60°C
• Protection Rating: IP65 (dustproof and waterproof front panel)
• Dimensions: 144 × 144 × 185 mm
• Weight: Approx. 1.5 kg
• Withstanding Voltage: 400 VAC (50/60 Hz), 1 minute
• Origin: Japan
• Warranty: 12 months
