Yokogawa NFBU050-S15 Short Base Module

Description

The NFBU050-S15 serves as the foundational base for mounting CPU and I/O modules in the FCN-RTU system. It supports modular expansion and is engineered for rugged field conditions, including wide temperature ranges and high altitudes.

Specifications

• Model: NFBU050-S15
• Type: Short Base Module
• Dimensions: 130 × 142.5 × 65.8 mm
• Weight: Approx. 1.5 kg
• Operating Temperature: -20°C to +70°C
• Altitude Rating: Up to 3000 m
• Power Consumption: Max 20 W
• Mounting Options: DIN rail or 19-inch rack
• Compatible Modules: Supports up to 3 I/O modules (with NFCP050 CPU)
• Suffix Codes:
  • -S: Standard type
  • 1: DIN rail-mounted
  • 5: Basic type with no explosion protection

Key Features

• Modular design for flexible system configuration
• Compact footprint ideal for remote installations
• Low power consumption for energy-efficient operation
• Wide environmental tolerance, including high altitude and temperature extremes
• Hot-swappable I/O modules for easy maintenance
• Built-in support for FCN-RTU CPU and I/O modules
• RAS features: Self-diagnostics, temperature monitoring, and I/O diagnostics
