Yokogawa SC42-SP24 Cconductivity Sensor

Description

The SC42-SP24 is part of Yokogawa’s SC42 series, engineered for accurate conductivity monitoring in a wide range of process applications. Its rugged construction and integrated temperature compensation make it ideal for harsh conditions and critical measurements.

Specifications

• Measurement Range: 0 to 2000 mS/cm
• Cell Constant: 0.1/cm
• Temperature Range: -10 to 120°C
• Pressure Rating: Up to 10 bar (145 psi)
• Material: Stainless steel electrodes, PVDF body
• Cable Length: Standard 5 m (customizable)
• Temperature Compensation: Automatic, 0 to 100°C, ±0.5°C accuracy
• Response Time: ≤5 seconds
• Operating Voltage: 12 to 24 VDC
• Accuracy: ±1% of reading or ±0.02 mS/cm (whichever is greater)
• Dimensions: Ø25 mm × 150 mm
• Weight: Approx. 0.3 kg
• Protection Rating: IP68 (fully submersible)
• Connection: 4-wire system for stable signal transmission

 Key Features

• Durable and corrosion-resistant materials for long-term reliability
• Fast response time for real-time monitoring
• Compact and lightweight design for easy installation
• Wide conductivity range suitable for diverse applications
• Seamless integration with Yokogawa systems
• Built-in Pt1000 RTD for precise temperature compensation
